Ref : 53232

7" (178 mm) Dia. Type 27 Vertical Depressed Center Wheel Grinder

2 hp, 6,000 RPM, Gearless, Rotational Exhaust, 5/8"-11 Spindle Thread

Share

  • Ideal for heavy-duty applications in foundries and shipyards. Fast stock, rust and scale removal.

  • Governor-controlled air motor maintains tool RPM under heavy load. Over-speed shut-off feature ensures maximum operator safety. Motor is gearless with less wearable parts, ensuring reduced maintenance and less down-time.

  • Insulated tool handle minimizes cold air transmission to the hand. Handle position is adjustable for operator comfort. Includes safety-lock throttle lever. For peak performance, use of optional 95870 Air Hose-1/2" (13 mm) diameter is recommended.

  • Model accepts optional Type 27 reinforced Depressed Center Wheels, 7" (178 mm) diameter. Wheel NOT included with tool. Covers more area in less time!

  • Overspeed Shut-Off Feature Ensures Maximum Safety

hp
2 hp
Max. RPM
6000
Air Inlet Thread
Exhaust Type
Hose I.D.
Vacuum Type
Motor Type
Height (in)
7 in
Height (mm)
165 mm
Length (in)
10 in
Length (mm)
241 mm
Weight (lb)
9.2 lb
Weight (kg)
4.17 kg
Width (in)
10 in
Width (mm)
254 mm
Tool Style
Vertical
Current Manual (Parts Page) PD11.23R
Tune-Up Kit Page 96552
Previous Manual (Parts Page) #1 PD11.23
